EQR TMT Bar (550D)

PREMIER EQR TMT, draw their strength from a computer controlled inline process of quenching , self-tempering & atmospheric cooling. Rolled out only from billet these toughened yet flexible bars have a perfect combination of physical & chemical properties with recommended EMF (Elongation at Maximum Force) edge

PREMIER EQR TMT, draw their strength from a computer controlled inline process of quenching , self-tempering & atmospheric cooling. Rolled out only from billet these toughened yet flexible bars have a perfect combination of physical & chemical properties with recommended EMF (Elongation at Maximum Force) edge

KEY FEATURES:
  • Available in fe500/fe500d/fe550d
  • Made only from billets
  • Adhering to all Indian & international standards
  • EMF APPROVED
  • Tested for Uniform elongation
PROPERTIES
Chemical
Elements Fe 500
(IS:1786/2008)
% Carbon (max.) 0.25
% Carbon equivalent (max.) 0.36
% Sulphur (max.) 0.04
% Phosphorus (max.) 0.04
% S + P (max.) 0.075
Physical
Elements Fe 500
Yield Stress (N/mm2) 520-650
Tensile Stress (N/mm2)( min.) 600 mm
Tensile/Yield Stress 1.12 - 1.18
% Elongation (min.) 18
% Uniform elong. upto max. stress min. 7.5
Application General / Seismic
APPLICATION

Premier TMT Bars have excellent ductility and higher fatigue strength, which make them suitable for structures and foundations that are subject to dynamic and seismic loading. They also possess excellent weld-ability because carbon is restricted below 25% and are resistant to fire hazards with no loss of strength up to 300 degrees Celsius. Better bend-ability also makes them easily workable at site and they are used in a wide range of applications:

  • General purpose concrete re-enforcement structures
  • Bridges
  • Flyovers
  • Dams
  • High rise buildings
  • Industrial structure
  • Concrete roads
  • Underground structures
